Rc 1/4 Scale Car
Chromoly Black Oxide Rod End Kit Heim Wcm (pcm Series 2 Piece)
USD $78.60
Condition : New
Free Shipping
Notify me when the price drops
We will email you if we find a lower price on this product!
QS Components, Inc.
__________________________
Quarter Scale Car 4130 Chromoly Black Oxide Rod End Kit
Established in 2002 in Yorktown, Indiana, QS Components, Inc. began by supplying suspension components and accessories for those in the RC car racing market and eventually expanded to full-size vehicles. This small home-based business has grown over the years into an impressive 18,000 square foot facility, complete with thousands of parts and CNC equipment.
While we continue to offer the same highly sought-after components that fueled our growth, over the years we have broadened our business horizons with the addition of a CNC fiber laser, CNC lathe, CNC mill, and a CNC press brake. These enhancements have significantly increased our inventory and opened us to new opportunities in the ever-growing manufacturing sector.
At QS Components Inc., our mission is to deliver the highest quality manufactured products & exceptional customer service.
Our team is ready to assist you Monday to Friday, 8 AM to 4 PM. Feel free to reach out by phone or by email.
Thank you for your business.
QS Components, Inc.
_________________________
Please Read Before Purchasing
Because our chromoly series rod ends have a larger body diameter than a standard economy rod end there may be some steering clearance issues on some makes and models of ¼ scale cars. QS Components, Inc. is not responsible for any clearance issues you may have.
ROD END KIT SPECS
3/16 10-32 RH Rod End Specs
Chromoly 4130 Steel Black Oxide Male Two Piece Rod End. Qty 6
Thread Size 10-32 RH
Ball Bore .1900
Ball Width .312
Centerline Length 1.250
Thread Length .750
Load Capacity 3,000 lbs.
Jam Nut Specs
Thread 10-32 RH Qty 6
Width 3/8
Height 1/8
Zinc Plated
3/16 10-32 LH Rod End Specs
Chromoly 4130 Steel Black Oxide Male Two Piece Rod End. Qty 6
Thread Size 10-32 LH
Ball Bore .1900
Ball Width .312
Centerline Length 1.250
Thread Length .750
Load Capacity 3,000 lbs.
Jam Nut Specs
Thread 10-32 LH Qty 6
Width 3/8
Height 1/8
Zinc Plated
1/4 X 1/4-28 RH Rod End Specs
Chromoly 4130 Steel Black Oxide Male Two Piece Rod End. Qty 6
Thread Size 1/4-28 RH
Ball Bore .250
Ball Width .375
Centerline Length 1.562
Thread Length 1.000
Load Capacity 4,500 lbs.
Jam Nut Specs
Thread 1/4-28 RH Qty 6
Width 7/16
Height 1/8
Zinc Plated
.
