PLASTIC ELECTRONIC PROJECT BOX HOBBY ELECTRONICS ELECTRICAL KIT

 THIS SALE IS (50 Each) PLASTIC ELECTRONIC ENCLOSURE CASES FOR YOUR ELECTRONIC PROJECTS.  ADAPT THE CASE TO USE FOR YOUR ELECTRONIC PROJECT ENCLOSURE.  THE OVERALL DIMENSIONS ARE 5 1/4 X 3 3/4 X 1 7/8 WITH A TAPERED FRONT.  THE CASE WAS MANUFACTURED FOR A SPECIFIC PURPOSE AND WAS DESIGNED FOR MOUNTING A CIRCUIT BOARD AT THE LOCATION THE 4 SCREW HOLES RETAIN THE COVER ON THE BOX.  YOU ARE ONLY BIDDING ON THE CASE AS SHOWN IN THE PICTURES.

THE DIMENSIONS OF THE SCREWS THAT HOLD THE BACK ON THE CASE ARE ROUGHLY 4 1/4 CENTER TO CENTER THE LONG DIRECTION AND  3 1/4 CENTER TO CENTER THE SHORT DIRECTION.  THESE ARE DIMENSIONS YOUR CIRCUIT BOARD MAY FIT PERFECT ON, OR USE ONE OR TWO OF THE SCREW HOLES AND ADD ADDITIONAL STANDOFF TO ALLOW CIRCUIT BOARD MOUNTING.

THERE IS ONE ROUND HOLE IN THE FRONT OF THE CASE WHICH WAS DESIGNED TO MOUNT A RESET BUTTON, AND ANOTHER ROUND HOLE IN THE FRONT THAT WAS DESIGNED TO ALLOW AN LED INDICATOR.  THE OTHER TWO SQUARE HOLES WERE DESIGNED TO ALLOW A TELEPHONE INPUT AND OUTPUT JACK, BUT ADAPT THESE HOLES TO WHATEVER YOUR PROJECT NEEDS.

SHIPPING IS INCLUDED VIA UPS GROUND.

SEE MY OTHER AUCTIONS FOR PURCHASING SMALLER QUANTITIES.

EBAY ITEM 175136120258 IS FOR A SINGLE UNIT.

EBAY ITEM 185276235342 IS FOR A QUANTITY OF 12 UNITS.
