Hobbywing Quicrun 1625 25a 2~3s Brushed Esc 1/18 1/16 Rc Car

For More Great Items Visit our eBay Store here-----> https://www.ebay.com/str/totsrc
QUICRUN 1625 Series 25 Amp Brushed ESC
For 1/16 1/18 Car

Specification

Hobbywing QuicRun WP 1625 25A Brushed ESC
Features
• Water-proof and dust-proof, suitable for all-weather condition races.
• Small size with built-in capacitor module.
• QUICRUN-WP-1625-BRUSHED ESC only has the Fwd / Rev / Br mode.
• Great current endurance capability.
• Great built-in BEC output capacity.
• Automatic throttle range calibration, easy to use.
• Easy to set the ESC parameters with jumpers.
• Multiple protections: Low voltage cut-off protection for battery / Over-heat protection / Throttle signal loss protection.
Specifications:
Fwd. Cont. / Peak Current :25A/100A
Rev. Cont. / Peak Current:25A/100A
Voltage Range:2-3S Lipo or 5-9 NiMH
Cars Applicable:1/20 1/18 &1/16: Touring Car, Buggy, Monster, Truggy
Motor Limit:
2S Lipo or 6 NiMH:280, 370 or 380 Size Motor: RPM<30000 @7.2V
3S Lipo or 9 NiMH: 280, 370 or 380 Size Motor: RPM<20000 @7.2V
Resistance:Fwd 0.003Ω, Rev 0.003Ω
BEC Output:1A / 6V (Linear Mode)
Dimension / Weight:34x24x14mm / 24g
Cooling Fan:Without cooling fan
Running Modes:Forward / Reverse / Brake

Package List
1 * 1625 25A ESC
1 * Adhesive Label Paper
1 * Cable Binding Tape
1 * Manual (English)
1 * Original Box
