High Speed Metal Gear 40kg Large Torque Digital Servo For Rc Car

WELCOME TO MY STORE

Description:

Name: Digital Servo

Pulse width: 500 μ s-2500 μ s =180°

Operating speed: (5V): 0.22sec60 °

Operating speed: (6V) 0.21sec60 °

Operating speed: (7.4v) 0.19sec60 °

Stall torque (5V): 31kg.cm

Stall torque (6V): 35kg.cm

Stall torque (7.4v): 40kg.cm

Motor: Coreless Motor

Dead band: 3 μ s

Ball Bearing: 2BB

Working Frequence: 1520 μ s/330hz

Dimensions: 41x20x40.5mm

Weight: 68g

Packing list:

1 x QY3240MG 40KG Large Torque Digital Servo

Note:

The color deviation is subject to actual system configuration and 1-3cm slight dimension difference is allowed due to manual measurement. Please refer to the size chart based on your actual figure.
